jcb 214 - Air Conditioning Data; Body and Framework: Technical Data

2 - 1
Section B Body and Framework
9803/3280
Section B
2 - 1
Issue 1
Technical Data
Air Conditioning (Option)
Binary Pressure Switch Settings
Low Pressure 1.96 bar (2.0 kgf/cm
2
28.4 lbf/in
2
)
High Pressure 27.5 bar (28 kgf/cm
2
400 lbf/in
2
)
Thermostatic Switch Settings
Cut out -0.6 °C (33.0 °F)
Cut in 4.2 °C (39.5 °F)
Refrigerant
R-134a 1.4 Kg Maximum charge
Oil
PAG Oil
Quantities:
Condenser 1.5 fluid oz. (42.6 ml)
Evaporator 3.0 fluid oz. (85.2 ml)
Receiver Drier 0.3 fluid oz. (8.5 ml)
Compressor None - pre charged
Hoses If more than 4 metres of hose is replaced,
then add 0.5 fluid oz. (15 ml) for every metre over 4 metres.
