jcb 214 - Front Axle - Steer Drive Type SD55, SD70

Transmission
9803/3280 Issue 1
Front Axle - Steer Drive Type SD55, SD70
15 - 1 15 - 1
Basic Operation
Section F Section F
Component Identification
The illustration shows a typical steer drive front axle.
A Yoke connection to propshaft
B Pinion
C Crownwheel
D Differential unit
E Drive shaft
F Universal coupling
G Reduction gear hub
H Steer swivel trunnion bearings
J Axle pivot
K Oil fill and drain plugs
A355950
B
A
E
F
G
C
D
H
J
K
