jcb 214 - Chart D - System Fails to Operate When the ‘Mode Switch’ Is Activated (Operator Seat Facing Forward)

37 - 5
Section D Controls
9803/3280
Section D
37 - 5
Issue 1
Precision Control (Servo)
YES
NO
YES
YES
NO
NO
Is the relevant wiring damaged?
START
Check for damage and carry out
continuity checks. Repair as
applicable.
Test and renew switch if applicable.
Does the system operate with the
operator seat set in the rear facing
position?
A402390
See Electrical Connections.
See Fault Finding Chart A - No Servo
Controls (system fails to operate)
See Electrical Switches, Joystick
Mounted Microswitches - Removal
and Replacement.
Is the mode switch functioning
correctly?
Fault Finding
Chart D - System Fails to Operate when the ‘Mode Switch’ is Activated (operator seat facing forward)
