23 - 8
Section E Hydraulics
9803/3280
Section E
23 - 8
Issue 1
Service Procedures
12 When the correct A.R.V. setting has been attained,
release the pressure in the test block. Remove the
A.R.V. sub-assembly and its setting body from the test
block.
Separate the A.R.V. sub-assembly from its setting
body.
Install the A.R.V. sub-assembly into its cap.
Auxiliary Relief Valves - Using Hand Pump
