jcb 214 - Page 673

81 - 5
Section F Transmission
9803/3280
Section F
81 - 5
Issue 1
Front Axle - SD55, SD70
Hub and Driveshaft - Dismantling (cont'd)
19 Use a puller to remove the trunnion seal and bearing.
S258270
255990
20 Withdraw drive shaft.
21 Prise out drive shaft inner oil seal J.
22 Remove circlip K
23 Remove bearing using tool 892/00225.
J
K
