jcb 8020 CTS - Main Component Locations

About the Product
Description
9 9821/6100-4 9
Before you do a maintenance task, make the product safe.
Main Component Locations
Figure 3.
F
J
K
M
L
D
B
N
A
C
E
H
G
A Bucket ram B Dipper (part of the excavator arm)
C Dipper ram D Boom (part of the excavator arm)
E Boom ram F Cab (contains the operator station)
G Engine cover H Tool box
J Chassis K Undercarriage
L Kingpost M Dozer blade
N Bucket
