Operation
Operator Seat
36 9821/6100-4 36
Operator Seat
General
CAUTION Position the seat so that you can comfortably reach the machine controls. Do not adjust the seat
while the machine is moving. You could have an accident if you operate the machine with the seat in the
wrong position.
The operator's seat can be adjusted for your comfort. A correctly adjusted seat will decrease the operator
fatigue.
Adjust the seat so that you can comfortably reach the machine controls.
For driving the machine, adjust the seat so that you can push the pedals fully down when your back is against
the seat back.
Stop using the machine if the operators seat becomes defective. Repair or replace the seat before using the
machine again.
Basic Seat
Figure 22.
A Lever (forward and backwards adjustment)
