Section E

Hydraulics

9803/6400

Section E

2 - 3

Issue 2*

Torque Specification

Nm kgf m lbf ft Part No. Remarks Qty

Hexagonal socket 265 27 195 12 M16 x 2 12

head bolts

Set Screw 57 ±11 5.8 ±1.09 42±8 21 M12 x 1.75 1

Nut 7140 728 5265 20 M62x2 1

Bucket Ram JS200 (see Note on Contents Page)

This table refers to the JS200 Bucket Ram sectional drawing

Nm kgf m lbf ft Part No. Remarks Qty

Hexagonal socket 367 38 270 12 M18 x 2.5 12

head bolts

Set Screw 57 ±11 5.8 ±1.09 42 ±8 22 M12 x 1.75 1

Nut 5790 590 4265 21 M70 x 2 1

Boom Ram JS240 (see Note on Contents Page)

This table refers to the JS240 Boom Ram sectional drawing

Nm kgf m lbf ft Part No. Remarks Qty

Hexagonal socket 520 53 380 12 M12 x 2.5 12

head bolts

Set Screw 57 ±11 5.8 ±1.09 42 ±8 22 M14 x 2.0 1

Nut 13200 1348 9746 21 M80 x 2 1

Dipper Ram JS240 (see Note on Contents Page)

This table refers to the JS240 Arm Cylinder sectional drawing

Nm kgf m lbf ft Part No. Remarks Qty

Hexagonal socket 367 38 270 12 M18 x 2.5 12

head bolts

Set Screw 57 ±11 5.8 ±1.09 42 ±8 21 M12 x 1.75 1

Nut 9340 952 6885 20 M70 x 2 1

Bucket Ram JS240 (see Note on Contents Page)

This table refers to the JS240 Bucket Ram sectional drawing
