6 - 2
Removal (continued)
4. Operate the traction motor to remove the track.
5. Lift the side of the undercarriage high enough to
permit drive sprocket removal. Support with wooden
blocks.
6. Stop the engine and operate the control lever to
relieve pressure in the hydraulic system.
Release pressure in the hydraulic tank (See Releasing
Tank Pressure in Routine Maintenance).
7. Remove the motor cover, attach identification tags to
the motor hoses, disconnect the hoses from the
motor and install plugs and caps.
Section F
Transmission
9803/6400
Section F
6 - 2
Issue 1
Motor/Gearbox
To Next Page
