Part No. 960-000187R_Rev. A © 2016 JCM American Corporation
15
DBV-500 Banknote Validator JCM® Training Overview November, 2016
Lecture Notes
S
ENSOR
T
EST
To test each sensor, block each Sensor, then consult Table 7 and confirm the
Bezel LED color changes to the correct color for the Sensor being tested.
Table 7 Sensor and LED Condition*
* If multiple sensors are active, the status of the sensor with lowest priority is
shown.
Sensor Name
Condition LED
Entrance Sensor Shielded RED
Centering Sensor Shielded
GREEN
Validation Sensor Shielded
BLUE
Exit Sensor Shielded
YELLOW
Stacker Home
Position Sensor
When the Pusher Plate is
NOT at Home Position
MAGENTA
Centering Home
Position Sensor
When the Centering
Mechanism is NOT
at Home Position
CYAN
Box Detection
Sensor
When the Cash
Box is installed
WHITE
