Part No. 960-000187R_Rev. A © 2016 JCM American Corporation
22
November, 2016 JCM® Training Overview DBV-500 Banknote Validator
Lecture Notes
B
ANKNOTE
R
EJECT
E
RRORS
Banknote Reject conditions are indicated by the Bezel LED Flashing Yellow
or Green. To identify the Banknote Reject Error, count the flashes between
pauses, then consult Table 10 to determine the Error, Causes and Solutions.
Table 10 DBV-500 Banknote Reject Errors, Causes and Solutions
Normal
Operation
Performance
Test
Error Causes and Solutions
Yello w (3) Yellow (2) Magnification
Error
Sensor detected improper levels; clean/calibrate
Yello w (3) Yellow (3) Denomination Invalid denomination type
Yello w (3) Yellow (4) Pattern Error
Abnormal Banknote pattern detected; clean,
calibrate
Yello w (3) Yellow (5) Photo Level Sensor levels incorrect; clean, calibrate
Yello w (3) Yellow (6)
Banknote
Length
Banknote longer/shorter than specified; clean
rollers
Yello w (3) Yellow (7) Pattern Error 1 Sensor readings do not compare; clean, calibrate
Yello w (3) Yellow (8)
Invalid
Banknote
Sensors detected the Banknote as invalid
Yello w (3) Yellow (9) Pattern Error 2 Sensor readings do not compare; clean, calibrate
Green (3) Green (1)
Skewed
insertion
Banknote inserted at an angle/crooked
Green (3) Green (2)
Remaining
Banknote
Banknote in Transport returned during
initialization
Green (3) Green (3)
Transport
Time-out
Sensors detected improper Banknote movement
Green (3) Green (4)
Banknote
Detection
Sensors detected Banknote with abnormal timing
Green (3) Green (5) Inhibit Setting
Banknote acceptance disabled by switch or Host
settings
Green (3) Green (6)
Return
Command
Banknote return commanded by Host
