GEN5™ Printer JCM® Training Overview September, 2017

LEANING

ARD

ROCEDURE

The Cleaning Card can be used for a quick cleaning of the GEN5 Print Head

and Paper Path.

To use the Cleaning Card, follow this procedure:

1. Open the EGM service door.

2. Pull the Printer out of the EGM on its Sliding Base.

3. Remove the Ticket Stock from the Paper Tray (Figure 8 a).

4. Remove the Cleaning Card from its protective packaging.

5. Insert the Cleaning Card into the Ticket In Slot (Figure 8 b). It will automati-

cally load in the proper position.

6. Press and hold the

Feed Button (Figure 8 c) to feed the Cleaning Card through

the Printer’s Paper Path.

7. Carefully remove the Cleaning Card from the Printer’s Ticket Out Slot.

8. Feed 2 or 3 Tickets through the Printer to remove Alcohol residue before reload-

ing Ticket Stock into the Paper Tray.

NOTE: Make sure the Printer’s Power Supply is properly connected.

NOTE: Each Cleaning Card is intended for single use only. Always use a new Cleaning

Card for each cleaning cycle.

Figure 8 Feed Cleaning Card into Ticket In Slot
