JCM GEN5 - Page 7

Part No. 960-000193R_Rev. A © 2017 JCM American Corporation
7
September, 2017 JCM® Training Overview GEN5™ Printer
6. To clean the Print Head Rollers (Figure 7 a) and the Presenter Assembly’s Feed
Rollers (Figure 7 b), turn the Rollers by hand while wiping them with a new Clean-
ing Wipe or a clean Microfiber cloth (slightly dampened with Isopropyl Alcohol).
a
Figure 6 Clean Print Head
a
b
Figure 7 Clean Print Head Rollers and Feed Rollers
