Jeep Cherokee 2000 - Right Headlamp; Right Heated Seat Switch

1
2
CAV CIRCUIT FUNCTION
1 B6 18WT/DB RIGHT FRONT WHEEL SPEED SENSOR (-)
2 B7 18WT
RIGHT FRONT
WHEEL SPEED
A
C
B
RIGHT
HEADLAMP
GROUNDZ1 18BKC
FUSED RIGHT LOW BEAM OUTPUTL44 18VT/RDB
FUSED RIGHT HIGH BEAM OUTPUTL34 18RD/ORA
FUNCTIONCIRCUITCAV
RIGHT FRONT WHEEL SPEED SENSOR (+)
SENSOR
RIGHT HEATED SEAT BACK DRIVER
GROUND
A
B
CAV CIRCUIT FUNCTION
A P89 18BR
B
Z1 18BK
RIGHT HEATED
SEAT BACK
RIGHT HEAT SEAT DRIVER
RIGHT HEATED SEAT BACK DRIVER
SENSOR FEED
D
C
B
A
RIGHT HEAT SENSE INPUT
SEAT CUSHION
RIGHT HEATED
P89 18BR
P141 18TN/LB
P144 18BK/YL
C
D
B
P86 18PK/BKA
FUNCTIONCIRCUITCAV
BLUE
YELLOW
VERTICAL MOTOR
SEAT FRONT
CAV CIRCUIT FUNCTION
1 P18 14YL/LG RIGHT POWER SEAT FRONT UP
2 P20 14RD/LG RIGHT POWER SEAT FRONT DOWN
RIGHT POWER
RIGHT HEATED
SEAT SWITCH
3
4
1
6
RIGHT SEAT HEATER SWITCH MUX
--
P134 18TN/RD
5
6
CAV CIRCUIT FUNCTION
1 P138 18VT/LG RIGHT SEAT LOW HEAT LED DRIVER
2
4
3
P140 18VT/BK
F83 18YL/DG FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
RIGHT SEAT HIGH HEAT LED DRIVER
Z1 18BK
GROUND
XJ 8W-80 CONNECTOR PIN-OUTS 8W - 80 - 65
