JEKKO SPX532 - Page 28

28
SPX532 – QUICKSTART GUIDE
12.4. PICK & CARRY FUNCTIONS
LEFT TRACK
FORWARD
CRANE ROTATION
CLOCKWISE
WINCH DOWN
RIGHT TRACK
FORWARD
WINCH UP
RIGHT TRACK
BACKWARD
LEFT TRACK
BACKWARD
CRANE ROTATION
COUNTER CLOCKWISE
MAIN BOOM
DOWN
MAIN BOOM UP
MAIN BOOM
TELESCOPIC OUT
MAIN BOOM
TELESCOPIC IN
WARNING!
The turret rotation function
is enabled!
The winch functions are
automatically disabled
when working in hook
mode!
