Jensen AWM910 User Manual

10
CD Operation
16. Insert and Eject CD
Insert CD
Press PUSH (16) to open the CD door. Insert a CD label-side out. Close the CD door.
Eject CD
Press PUSH again to open the CD door and stop CD play.
17. Play
Press CD (17) to begin disc play.
18. Pause
Press the play/pause button (18) to suspend and resume disc play.
19. Track Select
Briefly press the tune up (19a) or tune down (19b) button to move to the next or previous track.
Press and hold the tune up or tune down button to fast forward or fast reverse through the current
track. Fast forward and fast reverse will stop when the button is released.
20. Repeat (RPT)
Press RPT (20) during disc play to continuously repeat the selected track. Press RPT again to
stop repeating.
21. Intro Scan (SCAN)
Press INT(21) during disc play to play the first 10 seconds of each track on the current disc. Press
INT again to end the scan and play the selected track.
22. Random Shuffle (RDM)
Press RDM (22) during disc play to play all tracks on a CD in random, shuffled order. Press RDM
again to stop random play.

Jensen AWM910 Specifications

Power

power supply requirements	DC 12 Volts, Negative Ground
operating voltage	10-16VDC
total system power	50 Watts Maximum

FM Tuner

tuning range	87.5-107.9FM
sensitivity	<5uV
stereo separation at 1 kHz	>30dB

AM Tuner

tuning range	530-1710
sensitivity	<30uV

CD Player

frequency response	20Hz to 20kHz
signal to noise	65dB
compatible CD formats	Audio CD, CD-R, R/W

Amplifier

output power	25 Watts per Channel
output wiring	2/4 Speaker and Headphone System
output impedance	Compatible with 4-8 Ohm Speakers, 4 Ohm Load Minimum

Weight and Dimensions

overall dimensions	10-7/16"(W) x 7"(H) x 6-1/4"(D)
mounting dimensions	9-3/8"(W) x 6-1/8"(H) x 6-1/4"(D)
weight	3.5 lbs.(1.7 Kg)
