Jensen AWM910 User Manual

12
Specifications
General
Power Supply Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . DC 12 Volts, Negative Ground
Operating Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-16VDC
Overall Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-7/16"(W) x 7"(H) x 6-1/4"(D)
Mounting Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-3/8"(W) x 6-1/8"(H) x 6-1/4"(D)
Weight. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.5 lbs.(1.7 Kg)
FM Tuner
Tuning range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87.5-107.9FM
Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <5uV
Stereo separation @ 1 kHz . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . >30dB
AM Tuner
Tuning range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .530-1710
Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <30uV
CD Player
Frequency Response . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20Hz to 20kHz
Signal to Noise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65dB
Compatible CD Formats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Audio CD, CD-R, R/W
Amplifier
Output Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 Watts per Channel
Output Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2/4 Speaker and Headphone System
Output Impedance . . . . . . . . . . Compatible with 4-8 Ohm Speakers, 4 Ohm Load Minimum
Total system power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50 Watts Maximum
Specifications subject to change without notice.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause
undesired operation.
Note: The manufacturer is not responsible for any radio or TV interference caused by
unauthorized modifications to this equipment. Such modifications could void the User’s
authority to operate the equipment.
www.asaelectronics.com
© 2006 ASA Electronics Corporation
v.120606

Jensen AWM910 Specifications

Power

power supply requirements	DC 12 Volts, Negative Ground
operating voltage	10-16VDC
total system power	50 Watts Maximum

FM Tuner

tuning range	87.5-107.9FM
sensitivity	<5uV
stereo separation at 1 kHz	>30dB

AM Tuner

tuning range	530-1710
sensitivity	<30uV

CD Player

frequency response	20Hz to 20kHz
signal to noise	65dB
compatible CD formats	Audio CD, CD-R, R/W

Amplifier

output power	25 Watts per Channel
output wiring	2/4 Speaker and Headphone System
output impedance	Compatible with 4-8 Ohm Speakers, 4 Ohm Load Minimum

Weight and Dimensions

overall dimensions	10-7/16"(W) x 7"(H) x 6-1/4"(D)
mounting dimensions	9-3/8"(W) x 6-1/8"(H) x 6-1/4"(D)
weight	3.5 lbs.(1.7 Kg)
