Jensen AWM910 User Manual

9
AWM910
13. Preset Stations
Store Preset Stations
Six numbered preset buttons (13) store and recall stations for each AM and FM band. To store a
station, select a band (if needed), then select a station. Hold a preset button for three seconds.
The current station will be stored, and the corresponding preset number will appear in the display.
Recall Preset Stations
To recall a station, select a band (if needed). Press a preset button momentarily, and the unit will
tune to the corresponding stored station.
14. Equalizer Selector
The equalizer function applies preset sound effects to the unit’s audio output signal. Press EQ
(14) to step through the following equalizer options: Rock, Pop, Classic and USER. The equalizer
options will appear in the display as they are accessed. The Bass and Treble settings will be
saved in USER mode.
15. Headphone Operation
The headphone output is wired to the "A" speaker and is active when either "A" or "A & B"
speaker button is active. To use this feature, plug the headphones in to the 1/4" jack (15) and
adjust the volume to the desired level. When the headphones are plugged in, the speakers are
automatically disabled.

Jensen AWM910 Specifications

Power

power supply requirements	DC 12 Volts, Negative Ground
operating voltage	10-16VDC
total system power	50 Watts Maximum

FM Tuner

tuning range	87.5-107.9FM
sensitivity	<5uV
stereo separation at 1 kHz	>30dB

AM Tuner

tuning range	530-1710
sensitivity	<30uV

CD Player

frequency response	20Hz to 20kHz
signal to noise	65dB
compatible CD formats	Audio CD, CD-R, R/W

Amplifier

output power	25 Watts per Channel
output wiring	2/4 Speaker and Headphone System
output impedance	Compatible with 4-8 Ohm Speakers, 4 Ohm Load Minimum

Weight and Dimensions

overall dimensions	10-7/16"(W) x 7"(H) x 6-1/4"(D)
mounting dimensions	9-3/8"(W) x 6-1/8"(H) x 6-1/4"(D)
weight	3.5 lbs.(1.7 Kg)
