Jensen CM715K User Manual

11
®
CM715K
Dodge/Chrysler/Plymouth
1. Note the position of brackets on the exist-
ing radio.
2. Match the brackets found in the hardware
kit to the mounting tabs on your factory
radio.
3. Attach the supplied brackets to the chassis
of the radio with the four "machine thread"
Phillips type screws. Use two screws for
each bracket.
Jeep Grand Cherokee, Dodge
Avenger, Plymouth Sebring
1. Note the position of brackets on the exist-
ing radio.
2. Match the brackets found in the hardware
kit to the mounting tabs on your factory
radio.
3. Attach the supplied brackets to the chassis
of the radio with the four "machine thread"
Phillips type screws. Use two screws for
each bracket.
Typical Bracket Location
RESET
RESET
Untitled-3 4/10/99, 7:38 PM11

Jensen CM715K Specifications

CD Player

signal-to-noise ratio	>86 dB
frequency response	20 Hz - 20 kHz
channel separation	>65 dB

Tape Player

frequency response	±3 dB, 50 Hz-15 kHz
wow and flutter	0.13% JIS
signal-to-noise ratio (a-weighted)	65 dB

FM Tuner

tuning range	87.5 MHz-107.9 MHz
FM mono sensitivity	12 dBf
50 dB quieting sensitivity (stereo)	16 dBf

AM Tuner

tuning range	530 kHz-1720 kHz

Amplifier

total system power	160 watts peak
power output (front)	2 x 40W
power output (rear)	2 x 40W

General

power supply	11-16 VDC, negative ground
speaker output impedance	4-8 Ohms
fuses	fast blow AGC (2 amp and 10 amp)
