Jensen VX4010 - Using the Tft Monitor

16
VX4010
USING THE TFT MONITOR
Opening/Closing the TFT Monitor
Open the TFT Monitor
Press the OPEN button on the front panel to activate the mechanism that moves
the display panel into the viewing position.
Close the TFT Monitor
Press the OPEN button on the front panel to load the display panel back into the
compartment.
TFT Monitor Tilt Angle Adjustment
A known characteristic of TFT panels is that the quality of the display varies in
relationship to the viewing angle. To adjust the monitor angle for optimum
viewing:
1.
P
ress and hold the OPEN button on the front panel until a beep is heard.
2. To adjust the tilt of the display panel, turn the rotary volume ( ) knob.
3.
T
o store the new tilt setting, press and hold the OPEN button. The rotary
volume (
) knob will return to normal operation.
