JESS WELDING SynMag 2600 - DVK 5100 Spare Parts

SynMag 2600/3100/3600/4100/5100 11 Appendix
BA-0006 • 2020-02-08 EN - 25
11.3 DVK 5100 s pare parts
Fig. 18 DVK 5100 spare parts – external
Tab. 15 DVK 5100 spare parts – external
Pos. Name Item no.
A
Front panel 715.970.142
B
DVK 5100 control plate E231402
C
Housing 715.970.141
D
EURO central connector E950865
E
DVK 5100 hood 715.970.149
Fig. 19 DVK 5100 spare parts – internal
Tab. 16 DVK 5100 spare parts – internal
Pos. Name Item no.
A
Wire feed unit without motor E730081
Wire feed unit with motor E950865
B
Spool mandrel 306.050.003
A
E
B
C
D
A
B
