JESS WELDING SynMag 2600 - 3 Product Description; Technical Data

SynMag 2600/3100/3600/4100/5100 3 Product description
BA-0006 • 2020-02-08 EN - 5
3 Product description
3.1 Technical data
Production according to Euronorms EN 60974-1 and EN 60974-10
Fig. 1 SynMag 2600/3100 technical data
A SynMag 2600/3100
Tab. 1 SynMag 2600/3100 technical data
Power source SynMag 2600 SynMag 3100
Mains voltage 50 Hz 400 V AC 400 V AC
Fuse 16 A, slow-blow 16 A, slow-blow
Primary current max./eff. 15A/8A 17A/11A
Power supply cable 4 × 2.5 mm² 4 × 2.5 mm²
Mains plug 16 A 16 A
Idle voltage 18–40 V 18–42 V
Welding range 30–250 A 40–300 A
100% duty cycle 130 A 150 A
60% duty cycle 170 A 190 A
30% duty cycle 250 A 300 A
Protection type IP 23 IP 23
Type of cooling AF AF
Dimensions (L × W × H) 850 × 360 × 650 mm 850 × 360 × 650 mm
Weight 76 kg 77 kg
Noise level 70 dB(A) 70 dB(A)
