Introduction
This manual is provided by JET covering the safe operation and maintenance procedures for a JET
Model 22-44OSC Oscillating Drum Sander. This manual contains instructions on installation, safety
precautions, general operating procedures, maintenance instructions and parts breakdown. This machine
has been designed and constructed to provide consistent, long-term operation if used in accordance with
instructions set forth in this manual. If there are any questions or comments, please contact either your
local supplier or JET. JET can also be reached at our web site: www.jettools.com.
Specifications
Model number ........................................................................................................................... 22-44OSC
Stock numbers:
Sander kit complete ................................................................................................................ 659006K
Sander only .............................................................................................................................. 659006
Conveyor ............................................................................................................................. 649003-02
Stand ...................................................................................................................................... 659006S
Capacities:
Maximum board width (in.) .................................................................................................44 (two passes)
Minimum board length (in.) ................................................................................................................ 2-1/4
Maximum board thickness (in.) ................................................................................................................ 4
Minimum board thickness (in.) ............................................................................................................ 1/32
Motor and Electricals:
Conveyor motor ............................................ 1/30HP, 0.45A, 40 RPM, 43 inch-lb. torque, direct drive D.C.
Drum motor .....................TEFC induction, capacitor start, 1-3/4HP (1.3kW), 1PH, 115V only, 15.5A, 60Hz
Motor speed (RPM) ........................................................................................................................... 1720
Drum speed (RPM) ............................................................................................................................ 1700
Conveyor variable feed rate (FPM) ................................................................................ 0-10 (SandSmart)
On/off switch ............................................................................................ paddle style with removable key
Recommended circuit * ........................................................................................................................ 20A
* subject to local/national electrical codes.
Main Materials:
Frame........................................................................................................................................... cast iron
Drum ........................................................................................................................... aluminum extrusion
Cabinet............................................................................................................................................... steel
Dimensions:
Conveyor height from floor (in.) .............................................................................................................. 32
Drum size (in.) ............................................................................................................................... Ø5 x 23
Dust chute (in.) ........................................................................................................................................ 4
Cabinet height (in.) ................................................................................................................................ 29
Overall dimensions, assembled (in.) ............................................................................... 44L x 27W x 52H
Weights:
Net (lbs.) ............................................................................................................................................. 336
Shipping (lbs.) ..................................................................................................................................... 363
The above specifications were current at the time this manual was published, but because of our policy of
continuous improvement, JET reserves the right to change specifications at any time and without prior
notice, without incurring obligations.
