38
16.0 Electrical Connections for JWDS-2244/-2550
GM- GM+ LOAD2
LINE2
LOAD1
LINE1
SANDING MOTOR
TO BELT MOTOR
White
Black
Black
White
White
Black
POWER IN
White
Black
Green
Green
GROUND
CIRCUIT BOARD
POTENTIOMETER
