Unpacking
Separate all parts from the packing material.
Check each part against the Contents of the
Shipping Container and make certain that all
items are accounted for before discarding any
packing material.
Contents of the Shipping Container
A Head Assembly (1)
B Table and Bracket Assembly (1)
C Table Insert (1)
D Base (1)
E Column and Rack Assembly (1)
F Downfeed Handle (3)
G Arbor (1)
H Drift Key (1)
J Column Lock Handle (1)
K Chuck Key (1)
N Chuck (1)
O M10 x 40 Hex Cap Screws (4)
P Table Bracket Position Handle (1)
-- Owner’s Manual (1)
-- Warranty Registration Card
Tools Supplied for Assembly
L 3mm Hex Wrench
M 5mm Hex Wrench
Tools Required for Assembly
-- 17mm Box Wrench or a 6”-8” Adjustable
Wrench
Read and understand all
assembly instructions before attempting
assembly! Failure to comply may cause
serious injury!
Before Assembly
1. Remove the contents from the shipping
container.
2. Compare the contents of the shipping
container with the list found above. Report
any shortages or damage to your JET
distributor.
3. Clean all rust protected surfaces with
kerosene or a light solvent. Do not use
lacquer thinner, paint thinner, or gasoline.
These will damage plastic components and
painted surfaces.
