Familiarize yourself with the following safety notices used in this manual:
This means that if precautions are not heeded, it may result in minor injury and/or possible
machine damage.
This means that if precautions are not heeded, it may result in serious injury or possibly even
death.
4.0 Specifications
Model number .......................................................................... JJP-12 ................................................... JJP-12HH
Stock number .......................................................................... 708475 ....................................................... 708476
Cutterhead speed (RPM) ............................................................ 5500 ........................................................... 5500
Cutterhead diameter (in.) ............................................................ 2-3/4 ........................................................... 2-3/4
Number of knives .............................................................................. 3 .................................. 56 four-sided inserts
Knife size (LxWxT)(in.) ..................................................... 12 x 1 x 1/8 ...................................... 0.59 x 0.59 x 0.10
Dust port outside diameter (in.) ......................................................... 4 ................................................................. 4
Dust collection minimum CFM ...................................................... 400 ............................................................. 400
Jointer table size (LxW/in.) ...................................................... 55 x 12 ....................................................... 55 x 12
Table height from floor (in.) ....................................................... 33-1/2 ......................................................... 33-1/2
Maximum stock removal (in.) ......................................................... 1/8 .............................................................. 1/8
Fence size (LxH/in.) .................................................................. 43 x 6 ......................................................... 43 x 6
Fence tilt .......................................................................... 90° to 45° R ................................................ 90° to 45° R
Fence positive stop ....................................................... 90° and 45°R .............................................. 90° and 45°R
Planer table size (LxW/in.) ................................................ 21-1/4 x 12 ................................................. 21-1/4 x 12
Full width cutting depth (in.) ........................................................... 1/8 ..................................... See Table 1 below
Maximum workpiece thickness (in.) ........................................... 8 -3/4 ........................................................... 8-3/4
Maximum depth of cut (in.) ........................................................... 5/32 ..................................... See Table 1 below
Minimum length of workpiece (in.) .................................................... 6 ................................................................. 6
Feed rate .................................................................................. 20 fpm ........................................................ 12 fpm
Table movement per one handwheel revolution ......................... 5/32” ........................................................... 5/32”
Motor, TEFC ................................ 3HP, 1PH, 230V only, 60Hz, 12.5A ........... 3HP, 1PH, 230V only, 60Hz, 12.5A
Switch .............................................. magnetic switch with limit switch ................ magnetic switch with limit switch
Power cord (plug not included) ............................. 14AWG 300V, 8 ft. ..................................... 14AWG 300V, 8 ft.
Overall Dimensions (LxWxH/in.) ......................... 55 x 29-1/2 x 39-2/5 ................................... 55 x 29-1/2 x 39-2/5
Stand Footprint (LxW/in.) .................................................. 22 x 19-1/2 ................................................. 22 x 19-1/2
Net weight (lbs.) ............................................................................ 500 ............................................................. 500
Full Width Cutting Depths for Helical Cutterheads During Planing
Very dense and/or very tight grained lumber (e.g., Rock
Maple, Purpleheart, Ipe)
No more than 1/16” per full width cut per pass
Dense and/or tight grained lumber (e.g., Oak, Ash, Walnut) No more than 3/32” per full width cut per pass
Soft woods (e.g., Douglas Fir or White Pine) No more than 1/8” per full width cut per pass
Table 1
The specifications in this manual are given as general information and are not binding. JET reserves the right to
effect, at any time and without prior notice, changes or alterations to parts, fittings, and accessory equipment deemed
necessary for any reason whatsoever.
Read and understand the entire contents of this manual before attempting
assembly or operation! Failure to comply may cause serious injury!
