4.2 Specifications for JWBS-18

Model number ...................................................................................... JWBS-18 ......................................... JWBS-18-3

Stock number .......................................................................................... 714700 ................................................ 714750

Band saw nominal size .............................................................................. 18 in. ................................................... 18 in.

Motor and electricals:

Motor type…………………………………………….. totally-enclosed fan-cooled, induction, capacitor start ................

Horsepower ...................................................................................... 1.75 HP .................................................... 3 HP

Phase ................................................................................................... single .................................................. single

Voltage ................................................................ 115/230V (prewired 115V) ................................................... 230V

Cycle ...................................................................................................... 60Hz ................................................... 60Hz

Listed FLA (full load amps) ............................................................... 15/7.5 A .................................................... 12 A

Starting amps........................................................................................... 75A ..................................................... 53A

Running amps (no load) ......................................................................... 5.1A .................................................... 2.4A

Start capacitor.................................................................... 300MFD 250VAC ................................ 300MFD 250VAC

Run capacitor........................................................................... 40μF 250VAC ..................................... 60μF 300VAC

Power transfer ............................................................................... poly v-belt ............................................poly v-belt

On/off switch ..................................................... push button with paddle stop .............. push button, magnetic starter

Motor speed .................................................................................. 1720 RPM ........................................... 1720 RPM

Power cord length ..................................................................... 6 ft. (183 cm) ....................................... 6 ft. (183 cm)

Power plug installed ............................................................................... 115V ................................................... 230V

Recommended circuit size

..................................................................... 20A ..................................................... 20A

Sound emission

…………………………………………….75 dB at 40” (1000 mm) from blade, without load...............

Capacities and speeds:

Wheel diameter ............................................................................... 18-1/2 in. ............................................. 18-1/2 in.

Resaw capacity (cutting height) ............................................................ 16 in. ................................................... 16 in.

Throat capacity ..................................................................................... 18 in. ................................................... 18 in.

Maximum rip left of blade with fence ..................................................... 16 in. ................................................... 16 in.

Maximum rip right of blade with fence .............................................. 4-1/2 in. ............................................... 4-1/2 in.

Blade length .................................................... 150 in. (max. 150.9; min. 149) ............ 150 in. (max. 150.9; min. 149)

Blade width ............................................................................. 1/8 to 1-1/4 in. ..................................... 1/8 to 1-1/4 in.

Blade provided ................................................. Hook, 3/4" x 0.0256 thk 6 TPI ............. Hook, 3/4" x 0.0256 thk 6 TPI

Blade speed ................................................................... 2300 and 3800 FPM ........................... 2300 and 3800 FPM

Main Materials:

Table .................................................................................... ground cast iron .................................. ground cast iron

Trunnion ........................................................................................... cast iron .............................................. cast iron

Frame ..................................................................................................... steel .................................................... steel

Band wheels ..................................................................................... cast iron .............................................. cast iron

Tires .......................................................................................... polyurethane ....................................... polyurethane

Blade guides ................................................................................ ball bearing ......................................... ball bearing

Resaw fence .................................................................... extruded aluminum ............................. extruded aluminum

Paint finish ............................................................................. powder coating .................................... powder coating

Table, fence, miter gauge:

Table dimensions ......................................................... 27-1/4 x 20 x 1-5/8 in. ......................... 27-1/4 x 20 x 1-5/8 in.

Table tilt .............................................................................. Left 5°, Right 45° ................................ Left 5°, Right 45°

Table height from floor .......................................................... 37 in. (940 mm) ................................... 37 in. (940 mm)

Miter T-slot .................................................................. 3/4 in. W x 0.375 in. H ......................... 3/4 in. W x 0.375 in. H

Resaw fence size LxWxH ..............................................22-1/2 x 1-3/4 x 6 in. ........................... 22-1/2 x 1-3/4 x 6 in.

Miter gauge angle ............................................................. Left 45°, Right 45° ............................... Left 45°, Right 45°

Fence fine adjust knob, travel per one revolution ............. 0.05 in. (1.25 mm) ............................... 0.05 in. (1.25 mm)

Fence fine adjust knob, maximum travel ............................... 0.35 in. (9 mm) .................................... 0.35 in. (9 mm)

Dimensions:

Footprint (base size), LxWxH……………………………….29-1/2 x 21-5/8 x 2 in. (750 x 550 x 50.8 mm) ..................

Overall dimensions, LxWxH……………………………………36 x 34 x 80 in. (914 x 864 x 2032 mm) ........................

Shipping package dimensions…………………………………31 x 26 x 85 in. (780 x 660 x 2168 mm) ........................

Dust collection:

Dust port outside diameter ................................................. 4 in. (100mm) x 2 ................................ 4 in. (100mm) x 2

Minimum extraction volume required .............................................. 400 CFM ............................................. 400 CFM

Weights:

Net ....................................................................................... 502 lbs (228 kg) .................................. 502 lbs (228 kg)

Shipping ............................................................................... 572 lbs (260 kg) .................................. 572 lbs (260 kg)

Subject to local/national electrical codes.

The specified values are emission levels and are not necessarily to be

seen as safe operating levels. As workplace conditions vary, this information is intended to allow the user to make a

better estimation of the hazards and risks involved only.
