5.0 Specifications

Model number ................................................................................................................................................ JWSS-22B

Stock numbers:

Scroll saw with foot switch ............................................................................................................................727200B

Scroll saw with foot switch and stand ...........................................................................................................727200K

Optional stand only .......................................................................................................................................727200S

Motor and electricals:

Motor type ................................................................................................................................................ brushed DC

Horsepower ........................................................................................................................................ 1/16 HP (50W)

Phase ............................................................................................................................................................... single

Voltage ............................................................................................................................................................. 120 V

Cycle .................................................................................................................................................................. 60Hz

Listed FLA (full load amps) ................................................................................................................................ 1.3 A

Starting amps........................................................................................................................................................ 2 A

Running amps (no load) .................................................................................................................................... 0.5 A

On/off switch .................................................................................................................... rocker style, and foot pedal

Power cord............................................................................................................................. 18 AWG, 6 ft. (183 cm)

Power plug installed (saw and foot pedal) ...................................................................................................... 15 amp

Foot pedal cord length ....................................................................................................................................... 7.2 ft.

Recommended circuit and fuse/breaker size

...................................................................................................... 15A

Overload fuse ......................................................................................................................................... 3.15A, 250V

Blade and capacities:

Stroke .............................................................................................................................................. 3/4 in. (18.6 mm)

Speed ..................................................................................................................... variable, 400 to 1550 stroke/min.

Throat capacity ............................................................................................................................................ 22-3/8 in.

Blade type used ..................................................................................................................... plain-end (pinless) 5 in.

Blades included ...................................................................................................................................... (5) Skip type

Maximum cutting depth .......................................................................................................................... 2 in. (51 mm)

Arm tilt .................................................................................................................... 45 degrees left; 45 degrees right

Main materials:

Body and tool tray ............................................................................................................................................... steel

Main table ......................................................................................................................................... ground cast iron

Trunnion ............................................................................................................................................................. steel

Arm ............................................................................................................................................... steel, plastic cover

Table:

Table dimensions (LxW) ........................................................................................ 23.62 x 12.67 in. (600 x 322 mm)

Table slot width .................................................................................................................................................. 5 mm

Table height from floor, on optional stand ............................................................................... adjustable; 32 to 38 in.

Distance front edge of table to blade (approximate) ........................................................................ 3-5/8 in. (92 mm)

Dimensions:

Optional stand footprint (LxW) ................................................................................... 28 x 25-1/2 in. (711 x 648 mm)

Overall dimensions – saw only (LxWxH) ............................................ 33 x 15-1/2 x 17-1/2 in. (838 x 394 x 445 mm)

Overall dimensions – saw on stand (LxWxH) ......................................... 33 x 25-1/2 x 48 in. (838 x 648 x 1219 mm)

Shipping dimensions – saw only .................................................. 35.4" x 17.7" x 18.9" (900mm x 450mm x 480mm)

Dust collection:

Dust port outside diameter ................................................................................................................................ 1-1/2”

Recommended dust extraction volume ........................................................................ 300–350 CFM (8.5–10 CMM)

Weights:

Net weight, saw only .......................................................................................................................... 68.2 lbs (31 kg)

Net weight, optional stand only ......................................................................................................... 21.5 lbs (9.8 kg)

subject to local/national electrical codes.

L = length; W = width; H = height

Specifications in this manual were current at time of publication, but because of our policy of continuous improvement,

JET reserves the right to change specifications at any time and without prior notice, without incurring obligations.
