Jetmaster 60i - Internal Component Removal for Installation

Tertiary Air Tube Removal and V Board Bafe Removal
There are two tertiary air tubes located at the top of the inner rebox to bring air into the re. One is large and
one is small. Each tube is held in its position by a swing cam catch attached with a single 8mm bolt to the right
hand inner side of the rebox. The cam catch has a locator at its end that locates in a hole at the end of the
tube. When the cam catch locator is positioned in the tube hole the bolt is tightened to hold it in this position thus
trapping the tube. This ensures that the tube will not slide out and it keeps the tube with its tertiary air ports in the
correct position within the re.
Above the two tubes are three V board bafes. The two lower bafes are loose, just resting on the tubes and
touching the rear of the inner rebox. They are not xed with any xings. The one upper V board bafe is held in
place by a clamp that is xed at the front top of the inner rebox.
V-board panels
Cam Catch
Upper V-board bafe
Lower V-board bafes
Upper V-board clamp
Tertiary Air Tubes
8mm bolt
Locator
14
