Paint
It is strongly recommended that the re is protected from cement and plaster splashes during installation, as
these are difcult to remove from the surfaces.
Modular Construction
Due to the modular construction of the unit, you can for instance:
Fit the ue connector, air supply pipes and the outer box. The rest of the components can be kept in safe storage
while all rough building and nishing work is being completed. At the nal stage, the engine and nishing frame
can be tted.
This way there is less chance of aesthetic damage, or accidental damage to important components while building
work is in process.
Installation Requirements
Any under oor vents or openings within the builders opening should be sealed off.
The surface of the hearth and replace oor must be sufciently at to ensure that a good seal with the outer
rebox can be made and to enable the nishing frame to t. Any excessive unevenness (uneven tiles, stone,
etc.) should be rectied.
The front face of the replace should be reasonably at over the area covered by the outer rebox top and side
ange seals to ensure good sealing. These faces should be made good if necessary.
The appliance must not stand on combustible materials or carpets.
Unpacking
The re and the following components are packed in several cartons. Take care when unpacking the re to avoid
accidental damage. Particular care should be taken with the glass door and the air control mechanism.
Ensure that all the listed items are present before commencing installation.
l
Firebox consisting of an outer box and an inner rebox
l
Finishing Frame
l
Flue Adaptor
l
Roll of Insulation
l
Door operating tool
l
13mm Spanner to remove tertiary air tubes
l
Installation & Operating Instructions
l
Guarantee card
INNER BOX OUTER BOX FINISHING FRAME FLUE ADAPTOR DOOR
OPERATING
TOOL
