Jetmaster 60i - Inner Firebox Engine Fitting; Flue Adaptor Connection to Fire; Refitting the Internal Components; Fitting the Log Retainer (Optional)

Flue adaptor
Adaptor seal
M8 Bolt x 3
Inner Firebox “Engine” Fitting
Slide the inner box “engine” into the outer box. The engine contains easy grip areas that allow 2 people to easily
lift and slide the engine in place. Guides allow for easy location. Ensure that the inner box slides all the way to
the rear of the outer box. If an external air supply is used ensure that the exible pipe feeds through the rear of
the outer box and does not get trapped. The nal position should be with the front surface of the inner box ush
with the front surface of the outer box.
Flue Adaptor Connection to Fire
Once inner rebox is located in situ then the adaptor can be joined to the inner rebox. Working from the inside
it should be possible to pull the adaptor together with liner downwards into the recess at the top of the inner
rebox. Ensure the adaptor seal is in place and then pull down the adaptor. Once it has seated correctly then
the 3 bolts must be screwed into the nut xings to hold it in place. Take care not to damage the adaptor seal at
any stage.
A tight and effective seal must be made between the rebox and ue. It is essential that the system be
sealed at each joint so that the only air, which can reach the ue, is that which enters through the re. If the
ue of the re is not sealed, air could leak into the ue and chimney performance will be impaired. Alternatively
products of combustion could enter the room causing a serious health risk.
Retting the Internal Components
Once the re has been tted then replacement of the internal parts can be nished.
Ret the re components by reversing the sequence of steps above in the removal section.
Side V boards, rear V boards, bottom V boards, cast bottom grate, upper V board bafe, rear tube, lower V board
bafes, front tube and nally the door.
Check the door seals correctly.
Check the operation of the air control.
Fitting the Log Retainer (Optional)
The log retainer can be attached at the front of the re box by sliding down between the slots at each side of the
inner rebox at the front. The retainer should be tted the correct way around as shown in the diagram.
