Flue Adaptor with Liner
All res need some type of adaptor to connect to the ue. The Jetmaster ue adaptor supplied may be attached
to the base of the ue liner rst then pushed up while the outer rebox and inner re box are slid into place.
After the re is installed then, working from the inside it should be possible to pull the adaptor together with liner
downwards into the recess at the top of the re. Once it has seated correctly then the 3 bolts must be screwed
into the nut xings to hold it in place.
The Jetmaster re is not a structural unit; although very robust it is not designed to take the weight of the ue.
Therefore a structural lintel will need to be provided for clay liners or in the case of pre fabricated stainless steel
chimney the chimney manufactures recommended xing brackets or method must be used.
Flue Adaptor with Existing Flue
If the existing ue is to be used and the adaptor joined directly to the ue then the opening will need to be
prepared high enough to allow the outer box adaptor and any ue pipe to be slid in place and with sufcient room
to work to enable connection between re and ue.
Flue Liner or Flue
(designated size)
Inner & Outer box
assembly
Flue adaptor
ADAPTOR REQUIRES
ENOUGH SPACE TO CLEAR
THE OUTER BOX AND
INNER BOX
9
