TwinForce™ Series Waterblast Unit
Lighting And Reectors
Front and Side Lights and Reectors
The trailer is equipped with two front clearance
lights (Figure 24) to show the trailer’s width.
The lights will illuminate when the tow vehicle
has its lights turned on.
The two side marker lights and reectors show
the trailer’s presence and length. The lights
will illuminate when the tow vehicle has its
lights turned on.
Rear Lights and Reectors
The trailer is equipped with a row of rear mark-
ers lights (Figure 25) required for trailers over
80 in. (203 cm) wide. The lights will illuminate
when the tow vehicle has its lights turned on.
The two rear tail lights will illuminate when
the tow vehicle has its lights turned on. The
turn signals and brake lights illuminate when
the tow vehicle uses a turn signal or depresses
the brake pedal.
Figure 24: Front and Side Lighting.
Front
Clearance
Side Markers
Figure 25: Rear Lighting.
Rear Markers
Tail, Brake and Turn
