SECTION 2 - GENERAL SERVICE INFORMATION
3121741 – JLG Lift – 2-3
Table 2-2. Preventive Maintenance & Inspection Schedule.
AREA ON MACHINE
INTERVAL
PRE-DELIVERY
(a)
OR
FREQUENT
(b)
INSPECTION
6 MONTHS
ANNUAL
(c)
MAST ASSEMBLY
Mast Sections 1, 2, 5
Belt System (Ecolift Only) 516
Slide Pads 2, 3
Wear Screws 1 3
Flywheel Crank Assembly (Ecolift Only) 1, 5 14
Tool Tray 1
PLATFORM ASSEMBLY
Platform 1, 2, 4, 5
Guard Rails 1, 2, 4, 5
Gate Doors 1, 2, 5
Floor 1, 2
Lanyard Anchorage Point 1, 2
CHASSIS ASSEMBLY
Axle Wheels and Brake Assembly 1, 5, 7
Front Caster Wheels and Brake 1, 4, 5, 7
Bubble Level 1
Emergency Lowering Tool (Ecolift Only) 1, 5
FUNCTIONS/CONTROLS - (830P ONLY)
Platform Control 1, 5
POWER SYSTEM - (830P ONLY )
Electrical Connections 1
Battery and Cables 1, 20
Motor Contactor Solenoids
(d)
1, 5, 20
HYDRAULIC/ELECTRIC SYSTEM - (830P ONLY )
Hydraulic Pump 1, 9
Hydraulic Cylinder 1, 9
Hydraulic Lines, and Fittings 1, 9 1, 9
Hydraulic Reservoir, Cap, and Breather 1
Hydraulic Fluid 11 25
GENERAL
Operator and Safety Manual in Storage Box 21 21 21
ANSI and EMI Manuals/Handbooks Installed 21 21 21
Capacity Decals Installed, Secure, Legible 21 21 21
All Decals/Placards Installed, Secure, Legible 21 21 21
"Walk-Around" Inspection Performed 22
Annual Machine Inspection Due 21
No Unauthorized Modifications or Additions 21 21
All Relevant Safety Publications Incorporated 21 21, 22
General Structural Condition and Welds 2, 4 2, 4
All Fasteners, Pins, Shields, and Covers 1, 2
Function Test of All Systems 22 22
Paint and Appearance 7 7
Stamp Inspection Date on Frame 22
Notify JLG of Machine Ownership 22
