PowerBoost DC Converter System 1.5: Quick Start Guide
16995-01 rev. D
This document contains proprietary information. No part of this document should be reproduced
or distributed beyond its intended recipients without the express written consent of JMA Wireless. 11
Images below show connection points for power feeds from DC plant to PowerBoost inputs.
Torque value for all lugs on the PowerBoost unit is 65 lbf·in.
Photo below shows PB-19-SYS-8.
RETURN
Power input #2
-48V
(from CKT breaker)
Power input #1
-48V
(from CKT breaker)
RETURN
