PowerBoost DC Converter System 1.5: Quick Start Guide
16995-01 rev. D
This document contains proprietary information. No part of this document should be reproduced
or distributed beyond its intended recipients without the express written consent of JMA Wireless. 6
2. Confirm OVP equipment and operation
 Verify that Raycap OVP network configuration is appropriate for use with PowerBoost (per
system design). Lower Raycap OVP unit must have output port labeled “VBOOST
OUTPUT.” See table below:
Raycap Model
No. of
circuits
RS485 board
required
Description
RxxDC-2260-RM-48
6
Yes
6 Circuit rack
RxxDC-3315-PF-48
6
Yes
6 Circuit tower or base
RxxDC-4520-RM-48
12
No
12 Circuit rack
RxxDC-4520-RM-482
12
No
12 Circuit rack with (2) CPRI interface modules
RxxDC-6627-PF-48
12
No
12 Circuit tower or base
 Verify that Raycap OVP network telemetry is functioning correctly.
(lower OVP is reading voltage at upper OVP, from correct channels)
 OVP: Conductors correct connection has been verified (no crossed channels or
bridging/jumpering).
 Consult Raycap documents for troubleshooting OVP. See also general information later in
this document.
