PowerBoost DC Converter System 1.5: Quick Start Guide
16995-01 rev. D
This document contains proprietary information. No part of this document should be reproduced
or distributed beyond its intended recipients without the express written consent of JMA Wireless. 5
Two variants of PowerBoost are available:
• PB-19-SYS-8 (total 2U high), consists of 1 OMM unit married with 1 boost rack (single
Orion controller and 1 to 4 boost modules); supports up to 8 channels.
• PB-19-SYS-16 (total 3U high), consists of 1 OMM unit married with 2 boost racks (single
Orion controller and 1 to 8 boost modules); supports up to 16 channels.
1. Pre-installation checklist
Space:
System design performed; confirm equipment configuration.
Documented wiring diagram with components and distances labeled.
Rack space available for PowerBoost.
DC plant has capacity and breaker space to feed PowerBoost inputs.
Ground bus has sufficient location(s) available.
Shelter/cabinet cooling system has capacity for added equipment.
Components:
PowerBoost shelf and modules
Circuit breakers and current lug adapters
Compression lugs and heat shrink tubing
Wire (typically Telcoflex II or Telcoflex IV, 6AWG for PowerBoost outputs. Input AWG per
code and system design.)
Tools:
Standard hand tools
7/16 deep socket and driver capable of calibrated torque to 65 lbf·in.
Compression tool(s) for wire/lugs
Label maker
