Appendix G: Alarm information
The Orion controller provides output alarm relays (see table below), local LCD display, and web
access to alarm statuses. Alarms can be found on the controller display at Main Menu > Alarm
> Alarm List.
• From the home screen, press the Enter button to enter the Main Menu.
• Highlight the Alarm menu and press Enter.
• Highlight the Alarm List menu and press Enter.
PowerBoost alarm matrix:
sys low voltage or sys
battery on discharge
Event indicating that at least one of the
configured boost converters is not
running
The controller is not able to send a
correct configuration to the convertor
Results when a 50A breaker is tripped
This is the result of a failed controller
This is the result of not clearing device
history
Event received by the JMA Modbus
protocol. Indicated that there is an issue
with the radio head communication.
Over current threshold alarm above 33A
Overpower threshold alarm above
2200W
Over voltage threshold alarm above 70V
A positioning error occurred
Event indicating that at least one of the
configured boost convertors is in power
limit
sys output voltage
above 55.50 +/- 0.5
sys output voltage below
53 +/- 0.5
