PowerBoost DC Converter System 1.5: Quick Start Guide
16995-01 rev. D
This document contains proprietary information. No part of this document should be reproduced
or distributed beyond its intended recipients without the express written consent of JMA Wireless. 3
Appendix C: Connections from PowerBoost output to rack mount “near” OVP input 48
Appendix D: Orion GUI login .................................................................................... 49
Appendix E: OVP Configurations and channel mapping ........................................... 52
Appendix F: Converter status LEDs .......................................................................... 64
Appendix G: Alarm information ................................................................................ 66
Appendix H: Ordering guide ..................................................................................... 74
Appendix I: Commissioning and closeout checklist ................................................. 75
List of Contents:
• Pre-Installation checklist
• Unbox
• Mount in rack
• Connect ground
• Input power- route, pre-check polarity, then connect.
• Output connections
• Data and alarm connections
• Startup
Note:
• This information applies to product referred to as “PowerBoost 1.5,” identifiable by Orion
controller software version B8.97B01 or later.
o Also has firmware version label on circuit board at rear of chassis indicating FW
1.5.0.
• For information about product “PowerBoost 1.0,” identifiable by Orion controller software
version (circa) B8.30B32 and circuit board at rear indicating FW 1.0.2, see other
documents 16089-01 and 15525-01.
• To identify the Orion controller’s software via touch screen:
o Swipe right (or left) as needed to reach the main screen.
o Touch the icon labeled Controller or Device.
o Orion will reveal its installed software version, serial number, etc.
• Updated “PB 1.5” vs existing “PB 1.0”:
