TROUBLESHOOTING THE HYDRAULIC SYSTEM
SLIDE VALVE WILL NOT LOAD
OR UNLOAD
Solenoid coil burned out. Replace coil.
HV2 needle valve closed. Open valve.
Solenoid spool may be stuck or centering spring broken. Free spool or replace spring.
Solenoid may be mechanically actuated by inserting a piece of 3/16" rod against armature pin and pushing
spool to opposite end. Push “A” side to conrm unload capability. If valve works, problem is electrical.
Solenoid valve piston hung in bore or bolt loose. Check piston or tighten bolt.
SLIDE VALVE WILL LOAD BUT
WILL NOT UNLOAD
YY1 solenoid coil burned out. Replace coil.
Check valve in solenoid valve piston bad. Replace or repair.
Dirt inside solenoid valve preventing valve from operating both ways. Clean valve.
Solenoid may be mechanical ly actuated by inserting a piece of 3/16" rod against armature pin and pushing
spool to opposite end. Push YY1 valve to conrm unload capability. If valve works, problem is electrical.
Slipper seals worn out or damaged. Replace.
Check valve in slide valve piston sticking. Remove and clean check valve.
SLIDE VALVE WILL UNLOAD
BUT WILL NOT LOAD
YY2 solenoid coil burned out. Replace coil.
Dirt inside solenoid valve preventing valve from operating both ways. Clean valve.
Solenoid may be mechanically actuated by inserting a piece of 3/16" rod against armature pin
and pushing spool to opposite end. If valve works, the problem is electrical.
SLIDE STOP WILL NOT FUNC-
TION IN EITHER DIRECTION
Solenoid coil burned out. Replace coils.
Solenoid valve sticking. Replace valve.
SLIDE VALVE and/or SLIDE
STOP WILL NOT MOVE
Slipper seals worn out or damaged.
Unloader spindle or slide valve jammed.
Slide stop indicator rod jammed.
