Table 1: FX-PCG2621 physical features
Callout Physical feature: description and references
11 SA Bus - Terminal Block. See SA bus terminal block
12 Sensor Port - (SA Bus) RJ-12 6-Pin Modular Jack.
13 Binary Inputs - can be defined as: Dry Contact Maintained Pulse Counter Mode (50 Hz
at 50% duty cycle)
14 Universal Inputs - can be defined as: Voltage Analog Input (0-10 VDC), Current
Analog Input (4-20 mA), Resistive Analog Inputs (0-600k ohm): 0-2k Potentiometer.
RTD: 1k Nickle, 1k Platinum, or A99B SI. NTC: 10k Type L 10k JCI Type II, or 2.252k Type
II Dry Contact Binary Input
15 LED Status Indicators - See Table 9 for more information.
16 FC Bus Port - RJ-12 6-Pin MModular Jack. See FC Bus port for more information.
17 Cover Lift Tab
Wiring
CAUTION
Risk of Electric Shock.
Disconnect the power supply before making electrical connections to avoid electric shock.
Risque de décharge électrique.
Débrancher l'alimentation avant de réaliser tout raccordement électrique afin d'éviter tout risque de
décharge électrique.
CAUTION
Risk of Property Damage:
Do not apply power to the system before checking all wiring connections. Short circuited or improperly
connected wires may result in permanent damage to the equipment.
Mise En Garde: Risque de dégâts matériels:
Ne pas mettre le système sous tension avant d'avoir vérifié tous les raccords de câblage. Des fils
formant un court-circuit ou connectés de façon incorrecte risquent d'endommager irrémédiablement
l'équipement.
Important: Do not exceed the controller electrical ratings. Exceeding controller electrical
ratings can result in permanent damage to the controller and void any warranty.
Important: Use copper conductors only. Make all wiring in accordance with local, national,
and regional regulations.
Important: Electrostatic discharge can damage controller components. Use proper
electrostatic discharge precautions during installation, setup, and servicing to avoid damaging
the controller.
FX-PCG26 General Purpose Programmable Controller Installation Instructions6
