Expansion Options
The FX30E/FX60E provides for field-installable expansion
with two options:
• Option Cards: these are installed on connectors inside
the FX30E/FX60E base unit. See Option Cards.
• Accessory Modules: these are chained onto the
FX30E/FX60E’s 20-pin connector. See Accessories.
Option Cards
The FX30E/FX60E has two options slots for custom
option cards designed for use with the FX30E/FX60E.
Each slot has a 30-pin connector on the FX30E/FX60E
base unit.
Risk of Property Damage. Do not apply power to the
system before checking all wiring connections. Short
circuited or improperly connected wires may result in
permanent damage to the equipment.
MISE EN GARDE: Risque dégâts matériels. Ne pas
mettre le système sous tension avant d'avoir vérifié tous
les raccords de câblage. Des fils formant un court-circuit
ou connectés de façon incorrecte risquent
d'endommager irrémédiablement l'équipement.
Important: Power to the controller must be off when
installing or removing option cards or
damage will occur.
Important: Be careful to plug an option card into the
connector properly with its pins properly
aligned.
Option cards typically provide additional communication
capabilities, such as those listed in Table 2. For a list of
supported COM port and slot assignments for the option
cards, see Table 3.
Table 2: Option Card Details
Number of Option Cards Allowed
per Controller
DescriptionModel
One or twoLONWORKS FTT-10A adapter with a
2-position removable screw terminal plug
LP-FXLONFTT-1
One or twoDual, optically isolated, RS-485 adapter
with two 3-position removable screw
terminal connector plugs
LP-FXRS485-0
One or twoSingle port RS-232 adapter, with a DB-9M
connector
LP-FXRS232-0
OneWireless TEC Card (WTC) with direct
mount antenna
LP-FXWTC-0
OneSedona Framework™ option cardLP-FXSED-0
OneGPRS Modem cardLP-FXGPRS-0
OneGPRS Modem option card with Wyless™
SIM card
LP-FXGPRSW-0
Table 3: COM Port and Option Slot Assignments for FX30E/FX60E Option Cards
Onboard RS485Onboard RS232Option Slot 2Option Slot 1
COM2COM1NoneNone
COM2COM1NoneRS-232 = COM3
COM2COM1RS-232 = COM4RS-232 = COM3
COM2COM1RS-485 = COM4, COM5RS-232 = COM3
COM2COM1LON = LON1RS-232 = COM3
COM2COM1Sedona = COM4RS-232 = COM3
COM2COM1GPRS = COM4,COM5RS-232 = COM3
9FX30E/FX60E Supervisory Controllers Installation Instructions
