5-4
SM-18003
EXTERNAL INPUT/OUTPUT AND FUNCTION SETTING
7. Select “Yes” and press “OK”.
TheTestRunmenuwillbedisplayedafterthesettingis
conrmed.
If“No”isselected,thescreenwillreturnto"4".
OK
Function Selection:01-03
b1 00
01
23
b2 00
b3 00
b4 00
b5 00
Item Setting
/
Adj. Entr RtrnSel.
Back
Function Selection:01-03
01
23
b1 00
b2 00
b3 01
b4 00
b5 00
Item Setting
/
Adj. Entr RtrnSel.
Back
OK Back
OK
Input/Output:01-03
Input 1 00 CN3 1-2
Input 2 00 CN3 2-3
Output1 00 CN7 1-2
Output2 00 CN7 1-3
Output3 00 CN8 1-2
Item Setting Connector
Adj. Entr RtrnSel.
Back
OK
Input/Output:01-03
Input 1 00 CN3 1-2
Input 2 00 CN3 2-3
Output1 01 CN7 1-2
Output2 00 CN7 1-3
Output3 00 CN8 1-2
Item Setting Connector
Adj. Entr RtrnSel.
Back
1. Pressandhold“Menu”and“Back/Help”simultaneously
foratleastthreesecondsduringthenormalmode
(whenunitisnotoperated).TheTestRunmenuwillbe
displayed.
2. Select“FunctionSelection”or“Input/Output”fromthe
TestRunmenuandpress“OK”.
OK
Test Run Menu
Elevating Grille Setting
Input/Output
Thermistor Selection
Function Selection
01
/
03
Test Run
Entr RtrnSel.
Back
OK
Function Selection
01-01
All
01-02
01-03
01-04
Entr RtrnSel.
Back
3. Selecttheindoorunitbypressing“ ” and touch
“OK”.
(ThisscreenisNOTdisplayedwhenthenumberofan
indoorunitconnectedwiththecontrolleris
"1".Inthiscase,"4"willbedisplayed.)
Function Selection
4. Press “
”andselecttheitem.
5. Press “ ”andchangethesetting.
Input/OutputSetting
4. Press “
”andselecttheitem.
5. Press “
”andchangethesetting.
OK
Confirm function
selection setting?
Function Selection:01-03
Yes No
Sel. Entr Rtrn
Back
6. Press“OK”sothattheconrmationscreenwillbe
displayed.
8. Press“Back/Help”ontheTestRunmenutoreturntothe
normalmode.
(FigureforFunctionSelection)
Tosetotherunits,press“Back/Help”at"4"and"5"sothatthescreenwillreturnto"3".
(Ifthenumberofanindoorunitconnectedwiththecontrolleris"1",thescreenwillreturnto"1".)
●FunctionSelectionandInput/OutputSetting
