3-6
SM-18003
TROUBLESHOOTING
3.1.2
Location of Printed Circuit Boards (PCBs)
(1)
Outdoor Unit
Refer to the Service Manual for Outdoor Unit.
(2)
Indoor Unit
● Mini Cassette
PCB1
TB2
TB1
27
29
