Johnson Controls J ZB Series - Page 25

5808011-JIM-A-0320
Johnson Controls Ducted Systems 25
J08
(8.5)
208-3-60 14 83.1 22 3.03 6.8 5.5 20
None - - - 60.2 65.7 70 70
E09 6.8 1 18.9 60.2 65.7 70 70
E18 13.5 2 37.5 67.9 74.8 70 80
E24 18 2 50 83.5 90.4 90 100
E36 25.5 2 70.8 109.5 116.4 110 125
230-3-60 14 83.1 22 3.03 6.8 5.5 20
None - - - 60.2 65.7 70 70
E09 9 1 21.7 60.2 65.7 70 70
E18 18 2 43.3 75.1 82 80 90
E24 24 2 57.7 93.1 100 100 100
E36 34 2 81.8 123.3 130.1 125 150
460-3-60 6.4 41 10 1.6 3.4 2.2 20
None - - - 29 31.2 35 35
E09 9 1 10.8 29 31.2 35 35
E18 18 2 21.7 37.6 40.4 40 45
E24 24 2 28.9 46.6 49.4 50 50
E36 34 2 40.9 61.6 64.4 70 70
575-3-60 4.6 33 7 1.35 2.2 1.8 20
None - - - 19.6 21.4 20 25
E09 9 1 8.7 19.6 21.4 20 25
E18 18 2 17.3 29.4 31.6 30 35
E24 24 2 23.1 36.6 38.9 40 40
E36 34 2 32.7 48.6 50.9 50 60
J10
(10)
208-3-60 16.2 110 25 3.03 6.8 5.5 20
None - - - 65.1 70.6 80 80
E18 13.5 2 37.5 67.9 74.8 80 80
E24 18 2 50 83.5 90.4 90 100
E36 25.5 2 70.8 109.5 116.4 110 125
E54 40.6 2 112.7 161.9 168.8 175 175
230-3-60 16.2 110 25 3.03 6.8 5.5 20
None - - - 65.1 70.6 80 80
E18 18 2 43.3 75.1 82 80 90
E24 24 2 57.7 93.1 100 100 100
E36 34 2 81.8 123.3 130.1 125 150
E54 54 2 129.9 150.9 157.8 175 175
460-3-60 7.6 52 12 1.6 3.4 2.2 20
None - - - 31.4 33.6 35 40
E18 18 2 21.7 37.6 40.4 40 45
E24 24 2 28.9 46.6 49.4 50 50
E36 34 2 40.9 61.6 64.4 70 70
E54 54 2 65 75.5 78.3 80 90
575-3-60 5.1 43.8 8 1.35 2.2 1.8 20
None - - - 20.4 22.2 25 25
E18 18 2 17.3 29.4 31.6 30 35
E24 24 2 23.1 36.6 38.9 40 40
E36 34 2 32.7 48.6 50.9 50 60
E54 54 2 52 59.8 62 70 70
J06-12ZB Standard Indoor Blower - With Powered Convenience Outlet (Continued)
Size
(Tons)
Volt
Compressors
(each)
OD Fan
Motors
(each)
Supply
Blower
Motor
Pwr
Exh
Motor
Pwr
Conv
Outlet
Electric Heat Option
MCA
1
(Amps)
MCA
1
w/Pwr
Exh
(Amps)
Max fuse
2
/
breaker
3
size
(amps)
Max Fuse
2
/
Breaker
3
Size w/
Pwr Exh
(Amps)
RLA LRA MCC FLA FLA FLA FLA Model kW Stages Amps
