Johnson Controls J ZB Series User Manual

5808011-JIM-A-0320
26 Johnson Controls Ducted Systems
J12
(12.5)
208-3-60 18.6 149 29 2.1 9.6 5.5 20
None - - - 74.6 80.1 90 100
E18 13.5 2 37.5 74.6 80.1 90 100
E24 18 2 50 87 93.9 90 100
E36 25.5 2 70.8 113 119.9 125 125
E54 40.6 2 112.7 165.4 172.3 175 175
230-3-60 18.6 149 29 2.1 9.6 5.5 20
None - - - 74.6 80.1 90 100
E18 18 2 43.3 78.6 85.5 90 100
E24 24 2 57.7 96.6 103.5 100 110
E36 34 2 81.8 126.8 133.6 150 150
E54 54 2 129.9 154.4 161.3 175 175
460-3-60 9 60.9 14 1.26 4.7 2.2 20
None - - - 37 39.2 45 45
E18 18 2 21.7 39.3 42 45 45
E24 24 2 28.9 48.3 51 50 60
E36 34 2 40.9 63.3 66 70 70
E54 54 2 65 77.1 79.9 90 90
575-3-60 7.1 56 11 0.66 3.2 1.8 20
None - - - 26.5 28.3 30 35
E18 18 2 17.3 30.6 32.9 35 35
E24 24 2 23.1 37.9 40.1 40 45
E36 34 2 32.7 49.9 52.1 50 60
E54 54 2 52 61 63.3 70 70
1. Minimum Circuit Ampacity.
2. Dual Element, Time Delay Type.
3. HACR type per NEC.
J06-12ZB Standard Indoor Blower - With Powered Convenience Outlet (Continued)
Size
(Tons)
Volt
Compressors
(each)
OD Fan
Motors
(each)
Supply
Blower
Motor
Pwr
Exh
Motor
Pwr
Conv
Outlet
Electric Heat Option
MCA
1
(Amps)
MCA
1
w/Pwr
Exh
(Amps)
Max fuse
2
/
breaker
3
size
(amps)
Max Fuse
2
/
Breaker
3
Size w/
Pwr Exh
(Amps)
RLA LRA MCC FLA FLA FLA FLA Model kW Stages Amps
