J06-12ZB High Static Indoor Blower - Without Powered Convenience Outlet
Size
(Tons)
Volt
Compressors
(each)
OD Fan
Motors
(each)
Supply
Blower
Motor
Pwr
Exh
Motor
Pwr
Conv
Outlet
Electric Heat Option
MCA
1
(Amps)
MCA
1
w/Pwr
Exh
(Amps)
Max fuse
2
/
breaker
3
size
(amps)
Max Fuse
2
/
Breaker
3
Size w/
Pwr Exh
(Amps)
RLA LRA MCC FLA FLA FLA FLA Model kW Stages Amps
J06
(6.5)
208-3-60 9.6 73.8 15 3.03 6.8 5.5
None - - - 39.4 44.9 50 50
E09 6.8 1 18.9 39.4 44.9 50 50
E18 13.5 2 37.5 55.4 62.3 60 70
E24 18 2 50 71 77.9 80 80
E36 25.5 2 70.8 97 103.9 100 110
230-3-60 9.6 73.8 15 3.03 6.8 5.5
None - - - 39.4 44.9 50 50
E09 9 1 21.7 39.4 44.9 50 50
E18 18 2 43.3 62.6 69.5 70 70
E24 24 2 57.7 80.6 87.5 90 90
E36 34 2 81.8 110.8 117.6 125 125
460-3-60 5.1 37 8 1.6 3.4 2.2
None - - - 19.2 21.4 25 25
E09 9 1 10.8 19.2 21.4 25 25
E18 18 2 21.7 31.4 34.1 35 35
E24 24 2 28.9 40.4 43.1 45 45
E36 34 2 40.9 55.4 58.1 60 60
575-3-60 3.2 26 5 1.35 2.5 1.8
None - - - 14.5 16.3 15 20
E09 9 1 8.7 14.5 16.3 15 20
E18 18 2 17.3 24.8 27 25 30
E24 24 2 23.1 32 34.3 35 35
E36 34 2 32.7 44 46.3 45 50
J07
(7.5)
208-3-60 14 83.1 22 3.03 9.6 5.5
None - - - 46.8 52.3 60 60
E09 6.8 1 18.9 46.8 52.3 60 60
E18 13.5 2 37.5 58.9 65.8 60 70
E24 18 2 50 74.5 81.4 80 90
E36 25.5 2 70.8 100.5 107.4 110 110
230-3-60 14 83.1 22 3.03 9.6 5.5
None - - - 46.8 52.3 60 60
E09 9 1 21.7 46.8 52.3 60 60
E18 18 2 43.3 66.1 73 70 80
E24 24 2 57.7 84.1 91 90 100
E36 34 2 81.8 114.3 121.1 125 125
460-3-60 6.4 41 10 1.6 4.7 2.2
None - - - 22 24.2 25 30
E09 9 1 10.8 22 24.2 25 30
E18 18 2 21.7 33 35.8 35 40
E24 24 2 28.9 42 44.8 45 45
E36 34 2 40.9 57 59.8 60 60
575-3-60 4.6 33 7 1.35 3.2 1.8
None - - - 15.9 17.7 20 20
E09 9 1 8.7 15.9 17.7 20 20
E18 18 2 17.3 25.6 27.9 30 30
E24 24 2 23.1 32.9 35.1 35 40
E36 34 2 32.7 44.9 47.1 45 50
J08
(8.5)
208-3-60 14 83.1 22 3.03 9.6 5.5
None - - - 53 58.5 60 70
E09 6.8 1 18.9 53 58.5 60 70
E18 13.5 2 37.5 58.9 65.8 60 70
E24 18 2 50 74.5 81.4 80 90
E36 25.5 2 70.8 100.5 107.4 110 110
230-3-60 14 83.1 22 3.03 9.6 5.5
None - - - 53 58.5 60 70
E09 9 1 21.7 53 58.5 60 70
E18 18 2 43.3 66.1 73 70 80
E24 24 2 57.7 84.1 91 90 100
E36 34 2 81.8 114.3 121.1 125 125
460-3-60 6.4 41 10 1.6 4.7 2.2
None - - - 25.3 27.5 30 30
E09 9 1 10.8 25.3 27.5 30 30
E18 18 2 21.7 33 35.8 35 40
E24 24 2 28.9 42 44.8 45 45
E36 34 2 40.9 57 59.8 60 60
575-3-60 4.6 33 7 1.35 3.2 1.8
None - - - 16.6 18.4 20 20
E09 9 1 8.7 16.6 18.4 20 20
E18 18 2 17.3 25.6 27.9 30 30
E24 24 2 23.1 32.9 35.1 35 40
E36 34 2 32.7 44.9 47.1 45 50
