J12
(12.5)
208-3-60 18.6 149 29 2.1 9.6 5.5
None - - - 64.6 70.1 80 90
E18 13.5 2 37.5 64.6 70.1 80 90
E24 18 2 50 74.5 81.4 80 90
E36 25.5 2 70.8 100.5 107.4 110 110
E54 40.6 2 112.7 152.9 159.8 175 175
230-3-60 18.6 149 29 2.1 9.6 5.5
None - - - 64.6 70.1 80 90
E18 18 2 43.3 66.1 73 80 90
E24 24 2 57.7 84.1 91 90 100
E36 34 2 81.8 114.3 121.1 125 125
E54 54 2 129.9 141.9 148.8 175 175
460-3-60 9 60.9 14 1.26 4.7 2.2
None - - - 32 34.2 40 40
E18 18 2 21.7 33 35.8 40 40
E24 24 2 28.9 42 44.8 45 45
E36 34 2 40.9 57 59.8 60 60
E54 54 2 65 70.9 73.6 80 80
575-3-60 7.1 56 11 0.66 3.2 1.8
None - - - 22.5 24.3 30 30
E18 18 2 17.3 25.6 27.9 30 30
E24 24 2 23.1 32.9 35.1 35 40
E36 34 2 32.7 44.9 47.1 45 50
E54 54 2 52 56 58.3 60 70
1. Minimum Circuit Ampacity.
2. Dual Element, Time Delay Type.
3. HACR type per NEC.
J06-12ZB Standard Indoor Blower - Without Powered Convenience Outlet
Size
(Tons)
Volt
Compressors
(each)
OD Fan
Motors
(each)
Supply
Blower
Motor
Pwr
Exh
Motor
Pwr
Conv
Outlet
Electric Heat Option
MCA
1
(Amps)
MCA
1
w/Pwr
Exh
(Amps)
Max fuse
2
/
breaker
3
size
(amps)
Max Fuse
2
/
Breaker
3
Size w/
Pwr Exh
(Amps)
RLA LRA MCC FLA FLA FLA FLA Model kW Stages Amps
