5808011-JIM-A-0320
28 Johnson Controls Ducted Systems
J08
(8.5)
208-3-60 14 83.1 22 3.03 6.8 5.5
None - - - 50.2 55.7 60 60
E09 6.8 1 18.9 50.2 55.7 60 60
E18 13.5 2 37.5 55.4 62.3 60 70
E24 18 2 50 71 77.9 80 80
E36 25.5 2 70.8 97 103.9 100 110
230-3-60 14 83.1 22 3.03 6.8 5.5
None - - - 50.2 55.7 60 60
E09 9 1 21.7 50.2 55.7 60 60
E18 18 2 43.3 62.6 69.5 70 70
E24 24 2 57.7 80.6 87.5 90 90
E36 34 2 81.8 110.8 117.6 125 125
460-3-60 6.4 41 10 1.6 3.4 2.2
None - - - 24 26.2 30 30
E09 9 1 10.8 24 26.2 30 30
E18 18 2 21.7 31.4 34.1 35 35
E24 24 2 28.9 40.4 43.1 45 45
E36 34 2 40.9 55.4 58.1 60 60
575-3-60 4.6 33 7 1.35 2.2 1.8
None - - - 15.6 17.4 20 20
E09 9 1 8.7 15.6 17.4 20 20
E18 18 2 17.3 24.4 26.6 25 30
E24 24 2 23.1 31.6 33.9 35 35
E36 34 2 32.7 43.6 45.9 45 50
J10
(10)
208-3-60 16.2 110 25 3.03 6.8 5.5
None - - - 55.1 60.6 70 70
E18 13.5 2 37.5 55.4 62.3 70 70
E24 18 2 50 71 77.9 80 80
E36 25.5 2 70.8 97 103.9 100 110
E54 40.6 2 112.7 149.4 156.3 150 175
230-3-60 16.2 110 25 3.03 6.8 5.5
None - - - 55.1 60.6 70 70
E18 18 2 43.3 62.6 69.5 70 70
E24 24 2 57.7 80.6 87.5 90 90
E36 34 2 81.8 110.8 117.6 125 125
E54 54 2 129.9 138.4 145.3 150 175
460-3-60 7.6 52 12 1.6 3.4 2.2
None - - - 26.4 28.6 30 35
E18 18 2 21.7 31.4 34.1 35 35
E24 24 2 28.9 40.4 43.1 45 45
E36 34 2 40.9 55.4 58.1 60 60
E54 54 2 65 69.3 72 80 80
575-3-60 5.1 43.8 8 1.35 2.2 1.8
None - - - 16.4 18.2 20 20
E18 18 2 17.3 24.4 26.6 25 30
E24 24 2 23.1 31.6 33.9 35 35
E36 34 2 32.7 43.6 45.9 45 50
E54 54 2 52 54.8 57 60 60
J06-12ZB Standard Indoor Blower - Without Powered Convenience Outlet
Size
(Tons)
Volt
Compressors
(each)
OD Fan
Motors
(each)
Supply
Blower
Motor
Pwr
Exh
Motor
Pwr
Conv
Outlet
Electric Heat Option
MCA
1
(Amps)
MCA
1
w/Pwr
Exh
(Amps)
Max fuse
2
/
breaker
3
size
(amps)
Max Fuse
2
/
Breaker
3
Size w/
Pwr Exh
(Amps)
RLA LRA MCC FLA FLA FLA FLA Model kW Stages Amps
