Cool multiplier furnace - 3.5 ton
Table 35: Cool multiplier furnace - 3.5 ton
Furnace model Indoor coil model Total capacity Sensible capacity kW
TL8E080C16UH11 XAFC42E 0.99 0.94 0.97
TL8E080C16UH11 XAFC48F 0.99 0.94 0.97
TL8E080C16UH11 XAFD42E 1.00 0.96 0.98
TL8E080C16UH11 XAFD48F 1.00 0.95 0.98
TL8E080C16UH11 XAHC42E 0.99 0.94 0.97
TL8E080C16UH11 XAHC48F 0.99 0.94 0.97
TL8E080C16UH11 XAHD42E 1.00 0.96 0.98
TL8E080C16UH11 XAHD48F 1.00 0.95 0.98
TL8E080C16UH11 XAUC42E 0.99 0.94 0.97
TL8E080C16UH11 XAUC48F 0.99 0.94 0.97
TL8E100C20UH11 XAFC42E 1.00 0.94 0.96
TL8E100C20UH11 XAFC48F 1.00 0.94 0.96
TL8E100C20UH11 XAFD42E 1.00 0.95 0.96
TL8E100C20UH11 XAFD48F 1.00 0.94 0.96
TL8E100C20UH11 XAHC42E 1.00 0.94 0.96
TL8E100C20UH11 XAHC48F 1.00 0.94 0.96
TL8E100C20UH11 XAHD42E 1.00 0.94 0.96
TL8E100C20UH11 XAHD48F 1.00 0.94 0.96
TL8E100C20UH11 XAUC42E 1.00 0.94 0.96
TL8E100C20UH11 XAUC48F 1.00 0.94 0.96
TL9E080C16UH11 XAFC42E 1.02 0.99 0.98
TL9E080C16UH11 XAFC48F 1.02 0.98 0.95
TL9E080C16UH11 XAFD42E 1.01 0.98 0.93
TL9E080C16UH11 XAFD48F 1.01 0.97 0.93
TL9E080C16UH11 XAHC42E 1.02 0.99 0.98
TL9E080C16UH11 XAHC48F 1.02 0.98 0.95
TL9E080C16UH11 XAHD42E 1.01 0.97 0.97
TL9E080C16UH11 XAHD48F 1.01 0.97 0.93
TL9E080C16UH11 XAUC42E 1.02 0.99 0.98
TL9E080C16UH11 XAUC48F 1.02 0.98 0.95
TL9E100C20UH11 XAFC42E 1.00 0.94 0.96
TL9E100C20UH11 XAFC48F 1.00 0.94 0.96
TL9E100C20UH11 XAFD42E 1.00 0.95 0.96
TL9E100C20UH11 XAFD48F 1.00 0.94 0.96
TL9E100C20UH11 XAHC42E 1.00 0.94 0.96
TL9E100C20UH11 XAHC48F 1.00 0.94 0.96
TL9E100C20UH11 XAHD42E 1.00 0.94 0.96
TL9E100C20UH11 XAHD48F 1.00 0.94 0.96
TL9E100C20UH11 XAUC42E 1.00 0.94 0.96
TL9E100C20UH11 XAUC48F 1.00 0.94 0.96
TM8E080B12MP11 XAFC42E 1.00 0.96 0.96
TM8E080B12MP11 XAFC48F 1.00 0.94 0.96
TM8E080B12MP11 XAHC42E 1.00 0.95 0.98
TM8E080B12MP11 XAHC48F 1.00 0.94 0.96
TM8E080B12MP11 XAUC42E 1.00 0.96 0.96
TM8E080B12MP11 XAUC48F 1.00 0.94 0.96
TM8E080C16MP11 XAFC42E 1.04 1.04 1.01
TM8E080C16MP11 XAFC48F 1.04 1.03 0.99
TM8E080C16MP11 XAFD42E 1.02 1.03 0.98
TM8E080C16MP11 XAFD48F 1.02 1.03 0.98
TM8E080C16MP11 XAHC42E 1.02 1.03 1.00
